How to Use a Linksys RE9000 AC3000 WiFi Repeater

Authored by: Support.com Tech Pro Team

1. Introduction

In This Guide

You'll Learn:

• How to use your Linksys Range Extender.

2. How to Set Up Your Linksys RE9000 AC3000 Wi-Fi Range Extender

Show Me How

Clicking this button will open a new guide that will provide you with steps to resolve your issue.

3. How to Proceed?

Please select an option to proceed.

4. How to Update Your Linksys RE9000 AC3000 Wi-Fi Range Extender

Show Me How

Clicking this button will open a new guide that will provide you with steps to resolve your issue.

5. Retrieve Wi-Fi Credentials

Make sure your device is connected to your Range Extender via its Wi-Fi network, or physically using an ethernet cable before continuing.

1. Open your preferred web browser.


1. In the address bar at the top, enter extender.linksys.com and press Enter or Return.


1. Enter the password you set for your range extender, and select Login.


1. Select Basic Settings on the left.


1. On the right, scroll down to show the 2.4 Ghz + 5 GHz Extended Wireless Settings. You will see the Network Name and Password listed.


6. Connect to Network (Android)

Depending on your exact device (Smartphone or Tablet), and which generation you have, the menu theme and options might look slightly different on your screen. However, the steps should be similar across all Android devices and generations.

1. Open Settings.


1. Select Wi-Fi.


1. Select your extended network from the list.


1.

2. If you're asked for a password, it's the one you just setup on your range extender.

7. Connect to Network (iOS)

Depending on your exact device (Smartphone or Tablet), and which generation you have, the menu theme and options might look slightly different on your screen. However, the steps should be similar across all Apple iOS devices and generations.

1. Open Settings.


1. Select Wi-Fi.


1. Select the extended network you just setup from the list.


1.

2. If you're asked for a password, it's the one you just setup on your range extender.

8. Connect to Network (Windows 10)

Windows 10 may show slightly different options, but the steps should be similar across all versions of Windows 10.

1. Select the Network icon in the bottom right.


1. Select the the network name you setup during the extender setup.


1. Select Connect.


If you're asked for a password, it's the one you just setup on your range extender.

9. Connect to Network (macOS)

macOS may show slightly different options, but the steps should be similar across all versions and themes on macOS.

1. Select Wi-Fi from the menu bar, then select the extended network you just setup.


If you're asked for a password, it's the one you just setup on your range extender.

10. Status Light

There are three status lights for your Range Extender.

Main Light

This is the light directly on the top front of your Range Extender.

Off

Range Extender isn't getting power, or is turned off.

Solid Green

Turned on, with good signal strength.

Blinking Green

Booting up or updating firmware.

Blinking Orange

Ready for setup or not connected.

Solid Orange

Signal is weak from your router to the Range Extender. Move the Range Extender closer to the router.

WPS Light

The WPS light is on the side of the Range Extender.

Solid Orange

Your Range Extender is trying to make a WPS connection to your Router.

Off

WPS wasn't able to connect, or isn't being used.

Ethernet Ports

Each Ethernet port on the back of your Range Extender has a small light.

Off

No cable is connected, or the device can't be found over the Ethernet cable.

Solid Green

The connection to the other device is good.

Blinking Green

Data is going over the connection.

11. Check Network Status

You can check the status of your Linksys RE9000 Range Extender in two ways:

• On the device
• On a computer or mobile device with a web browser

The type and amount of network related information that you get depends on which method you use.

On Your Range Extender

1. Check the indicator light on the front of the range extender:


1.

2. Off

1. Range Extender isn't getting power, or is turned off.
2. Solid Green

1. Turned on, with good signal strength.
2. Blinking Green

1. Booting up or updating firmware.
2. Blinking Orange

1. Ready for setup or not connected.
2. Solid Orange

1. Signal is weak from your router to the Range Extender. Move the Range Extender closer to the router.

On Your Computer

1. Launch the web browser that you use to surf the web.


1. Navigate to one of the following addresses:

• http://extender.linksys.com


• If you know the IP address assigned to your range extender you can enter that instead.


•

• This is an example IP address and will likely not match the one your range extender has.

12. Location

Finding the most optimal location for your Range Extender in your home is important for both maximizing your signal range and wireless coverage. The light on top of your Range Extender will help you locate a good position.

Move Closer or Further Away

When the light is orange, the signal is too weak or too strong to the Range Extender. Move it closer or farther from your router.

Good Location

A green light indicates the Range Extender is in a good location.

You can move your Range Extender from outlet to outlet using the light to determine the best place in your home.

In general, you want your Range Extender at least six feet away from your router. At most, you want it half-way between where your router is, and where you want the signal to reach. Finding and testing multiple locations may be necessary if wireless interference is a factor within your home.
